(RXLG-2000W-30) Brake Resistor

Code: RXLG-2000W-30R

Brake modules and resistors are used together with a frequency converter for fast braking or control of mechanisms with high inertia, to dump excess braking energy from the DC link of the frequency converter. The brake module connects the DC link to the brake resistor unit. In frequency converters with a power of up to 18.5 kW, brake modules are built-in. Frequency converters with a power of 22 kW and more require the installation of an external brake module. Braking resistors dissipate excess braking energy in the form of heat.

Braking resistors can be manufactured in an aluminum housing or a ceramic housing.

The braking module, power and resistance of the braking resistors are selected in accordance with the recommendations of the frequency converter manufacturer.

Technical Parameters

Type	Rated Power (W)	Product Picture	Dimension (mm)							Connecting Wire (mm)	Lead length (mm)	Terminal	Weight (Kg)	Resistance value range(Ω)	Connection
			A	B	C	D	E	F	G
RXLG	60	Picture A	115	98	40	20	5.5			1.5	500	2-5S	0.165	1Ω-10KΩ	Lead wire
RXLG	80		140	123	40	20	5.5			1.5	500	2-5S	0.2	1Ω-10KΩ
RXLG	100		165	148	40	20	5.5			1.5	500	2-5S	0.24	1Ω-10KΩ
RXLG	120		190	173	40	20	5.5			1.5	500	2-5S	0.28	1Ω-10KΩ
RXLG	150		215	198	40	20	5.5			1.5	500	2-5S	0.32	1Ω-10KΩ
RXLG	200		165	147	60	30	5.5			1.5	500	2-5S	0.464	1Ω-10KΩ
RXLG	300		215	198	60	30	5.5			1.5	500	2-5S	0.62	1Ω-10KΩ
RXLG	400		265	247	60	30	5.9			1.5	500	2-5S	0.8	1Ω-10KΩ
RXLG	500		335	317	60	30	5.9			1.5	500	2-5S	1.03	1Ω-10KΩ	Terminal
RXLG	800		400	382	61	59		40.5	5.5			M6	2.2	1Ω-10KΩ
RXLG	1000	Picture B	400	384	50	107		30	5.5			M6	3.6	5Ω-10KΩ
RXLG	1200		450	434	50	107		30	5.5			M6	4	5Ω-10KΩ
RXLG	1500		485	469	50	107		30	5.5			M6	4.35	5Ω-10KΩ
RXLG	2000		550	534	50	107		30	5.5			M6

Connecting Wire (mm)	Lead length (mm)	Terminal	Weight (Kg)	Resistance value range(Ω)	Connection
			A	B	C	D	E	F	G
RXLG	60	Picture A	115	98	40	20	5.5			1.5	500	2-5S	0.165	1Ω-10KΩ	Lead wire
RXLG	80		140	123	40	20	5.5			1.5	500	2-5S	0.2	1Ω-10KΩ
RXLG	100		165	148	40	20	5.5			1.5	500	2-5S	0.24	1Ω-10KΩ
RXLG	120		190	173	40	20	5.5			1.5	500	2-5S	0.28	1Ω-10KΩ
RXLG	150		215	198	40	20	5.5			1.5	500	2-5S	0.32	1Ω-10KΩ
RXLG	200		165	147	60	30	5.5			1.5	500	2-5S	0.464	1Ω-10KΩ
RXLG	300		215	198	60	30	5.5			1.5	500	2-5S	0.62	1Ω-10KΩ
RXLG	400		265	247	60	30	5.9			1.5	500	2-5S	0.8	1Ω-10KΩ
RXLG	500		335	317	60	30	5.9			1.5	500	2-5S	1.03	1Ω-10KΩ	Terminal
RXLG	800		400	382	61	59		40.5	5.5			M6	2.2	1Ω-10KΩ
RXLG	1000	Picture B	400	384	50	107		30	5.5			M6	3.6	5Ω-10KΩ
RXLG	1200		450	434	50	107		30	5.5			M6	4	5Ω-10KΩ
RXLG	1500		485	469	50	107		30	5.5			M6	4.35	5Ω-10KΩ
RXLG	2000		550	534	50	107		30	5.5			M6	4.9	5Ω-10KΩ
